Parker Grade Instrumentation Tube
派克儀器管路
正確的儀器管路選擇和安裝是構建無泄漏可靠管路系統的關鍵因素。使用派克的儀器級管及其配件范圍將有助于您的資產完整性計劃。Correct instrument tubing selection and installation are key ingredients in building leak-free reliable tubing systems. Utilising Parker's instrument grade tube with its range of fittings will help with your asset integrity program.
正確選擇和安裝儀表管是確保儀表液系統可靠，無泄漏的關鍵。儀表管的材料和規格需要仔細地與應用要求相匹配，以獲得最佳的長期性能和耐腐蝕性能。派克是全球大的海上應用儀表產品供應商之一，而派克牌級管已成為新的油氣儀表工程項目受歡迎的設計選擇。與標準300系列和雙相不銹鋼相比，該材料具有更強的抗氯化物點蝕，縫隙腐蝕和應力腐蝕開裂的能力，使其成為在惡劣環境中需要較長使用壽命的應用的理想選擇。派克6Mo級管材現在也可提供，以補充管件產品，并且不久還將提供符合NORSOK M650的管材。
派克的材料采購，制造和材料科學能力是業內好的。我們生產的儀器管材的材料范圍非常廣泛，包括316不銹鋼，6Mo，904L，合金400，合金625，合金825，合金C-276，SAF 2507，Sanacro和鈦。我們還提供各種規格的管子。我們的英制管尺寸為1/16“，1/8”，1/4“，5/16”，3/8“，1/2”，5/8“，3/4”和1“外徑，而我們的公制尺寸分別為3 mm，6 mm，8 mm，10 mm，12 mm，14 mm，15 mm，16 mm，18 mm，20 mm，22 mm和25 mm外徑外徑同樣可以選擇。英制尺寸為0.014英寸，0.035英寸，0.049英寸，0.064英寸，0.065英寸，0.083英寸，0.095英寸，0.109英寸，0.120英寸和0.028英寸，而公制尺寸為0.5毫米，
市場：
- 海上油氣
- 陸上油氣
- 石油化工
- 化學
特性/優點：
- 符合NORSOK M-650
- NACE MR0175 / ISO 15156
- 直段或盤管
應用：
- 中低壓儀表管
- 海水裝卸設備
- 紙漿廠漂白系統
- 高層油蒸餾塔和設備
- 脫鹽設備
- 煙氣脫硫洗滌塔
兼容產品
- A-LOK雙插芯壓縮配件
- CPI單壓縮配件
Correct selection and installation of instrument tubing are key to ensuring reliable, leak-free performance of instrumentation fluid systems. Instrument tubing materials and specifications need to be carefully matched to application requirements for optimum long-term performance and resistance to corrosion.
Parker is one of the world’s largest suppliers of instrumentation products for offshore applications, and Parker Grade tube has become the most popular design choice for new oil and gas instrumentation engineering projects. Compared to standard 300 series and duplex stainless steel, the material offers much greater resistance to chloride induced pitting, crevice corrosion and stress corrosion cracking, making it ideal for applications demanding long in-service life in hostile environments. Parker Grade 6Mo tubing is also now available to complement the tube fitting offering, and will also shortly be available in conformance to NORSOK M650.
Parker's materials sourcing, manufacturing and materials science capabilities are some of the finest in the industry. We produce instrument tubing in an exceptionally wide range of materials, including 316 Stainless Steel, 6Mo, 904L, Alloy 400 , Alloy 625, Alloy 825, Alloy C-276, SAF 2507, Sanacro and Titanium. We also offer an extremely wide range of tube sizes. Our imperial tube sizes are 1/16", 1/8", 1/4", 5/16", 3/8", 1/2", 5/8", 3/4" and 1" O.D., while our metric sizes are 3 mm, 6 mm, 8 mm, 10 mm, 12 mm, 14 mm, 15 mm, 16 mm, 18 mm, 20 mm, 22 mm and 25 mm O.D. There is an equally wide choice of tube wall thickness. Imperial sizes are 0.014", 0.035", 0.049", 0.064", 0.065", 0.083", 0.095", 0.109", 0.120" and 0.028", while metric sizes are 0.5 mm, 0.6 mm, 1 mm, 1.2 mm, 1.24 mm, 1.5 mm, 1.65 mm, 1.8 mm, 2.0 mm, 2.11 mm and 2.2 mm.
Markets:
- Oil and Gas Offshore
- Oil and Gas Onshore
- Petrochemical
- Chemical
Features/Benefits:
- NORSOK M-650 compliant
- NACE MR0175/ISO 15156
- Straight sections or in coils
Applications:
- Low and medium pressure instrument tubing lines
- Seawater handling equipment
- Pulp mill bleach systems
- Tall oil distillation columns and equipment
- Desalination equipment
- Flue gas desulfurization scrubbers
Compatible Products
- A-LOK double ferrule compression fittings
- CPI single compression fittings
技術指標
Technical Specifications
Tube Wall Thickness: 0.049"
Material: SAF 2507
Certificates: N/A
Tube Type: Straight
Tube O.D.: 1/2"
Materials of Construction: SAF 2507
Tube O.D.: 1/2 inch
Tube Wall Thickness: 0.049"
Specifications Met: N/A
Tube Type: Straight
|
